CE marked 400W powerful high frequency Electrosurgical unit

HV-300 LCD Electrosurgical Generator

Intelligent Device System
Microprocessor controlled with a wide TFT LCD Touch Screen, clean image quality. The settings and working modes of operation are changed by touching icons on the screen, ensures the users with easy access to all functions, satisfying all the surgeries demands with safety, flexibility, reliability and convenience.
Characteristics:
Equipment are designed for conventional Electrosurgical procedures with the ability to automatically adjust, designed for various operations.

Activation:
Designed to perform cutting and coagulation during surgical procedures, output activated by handswitch or Footswitch
REM(Return Electrode Monitoring)
Return electrode (for Monopolar) with quality monitoring system(REM).
This REM system continually monitors patient impedance levels and deactivates the generator if a fault in the patient/return electrode contact is detected, at the same time with Audible and Visual Alarms, as well as real-time dynamic display of the contact quality on the screen between the negative plate and the patient's skin.


Automatic self-test
When switch on the machine, it will start automatically self-test routine prior to operation.

Real-time Monitoring and Instance Response System for Tissue Density

This proprietary technology delivers optimal clinical effects through continuous synchronization of current and voltage. It samples the current and voltage 450,000 times per second which enables it to respond to tissue impedance changes in less than 10 milliseconds, which ensuring the machine achieves optimum energy output levels quicker and more accurately – ensuring that only the precise voltage needed is safely delivered to each tissue type.

Monopolar Cut
-Multi Monopolar outlet, 3-pin (4mm) outlets and Laparoscopic Microphone head (4mm, 8mm ) outlet
-Different effects for cutting modes , pure cut for fast tissue dissection, while blend cut with a slight coagulation effect
Monopolar Coagulation
-Different coagulation modes provides precise, moderate, enhanced, contact-less coagulation effects
-Possibility of argon plasma coagulation

Bipolar
-Coagulation with Forceps for contact coagulation without sparking
Upgrade Interface:
USB/RS232 interface available to connect with computer, which allows remote problem detect as well as further software upgrade.
Compatible with other Equipment
1.Argon gas module.
2.Optimum Smoke Evacuation System
Multilanguage Available
Language options: English, Spanish, Portuguese, Turkish and etc.

Application of Use
General Surgery; Gastroenterology, Dermatology;
Vascular Surgery; Obstetrics and Gynecology
Heart/Thoracic Surgery; ORL/ENT; Minimally Invasive Surgery(MSI)
Cerebral surgery; Neurosurgery, Orthopedics & Plastic Surgery;
Trans Urethral Resection (TUR) and etc.
Certificate
Machines are qualified by internationally recognized construction standards such as: CE, FDA, ISO 13485, ISO 9001.
