Intelligent Device System

The intuitive design and user-friendly set- up of the AHANVOS Electrosurgical Generator (diathermy) for us in the modern operating room, it features both monopolar and bipolar functions to satisfy all the surgeries demands with safety, f lexibility, reliability and convenience.

Touch Screen

AHANVOS electrosurgical system is controlled with a wide TFT LCD touch screen (8 inch), clean and shaper image quality, which provides the user with easy access to all diathermy functions. The settings or modes of operation are changed by touching icons on the screen. To ensure maximum ease of operation there are no extra buttons or knobs.

REM (Return Electrode Monitoring)

Return electrode contact quality monitoring system (REM). The REM system continually monitors patient impedance levels and deactivates the generator if a fault in the patient/return electrode contact is detected, which minimize the danger of burning incidents. Such electrode can be identified by its split appearance i.e. two separate areas and a special plug with center pin.

Automatic Self-Test

Once switched on, AHANVOS systems perform a comprehensive internal test

Real-time Monitoring and Instance Response System for Tissue Density

This proprietary technology delivers optimal clinical effects through continuous synchronization of current and voltage, It samples the current and voltage 450,000 times per second which enables it to respond to tissue impedance changes in less than 10 milliseconds, which ensuring the machine achieves optimum energy output level quicker and more accurately-ensuring that only the precise voltage needed is safely delivered to each issue type.

Ligasure Vessel Sealing (Seal-Safe)

With above mentioned Real-Time and instance response system, it enables permanent sealing up blood vessels with a diameter up to 7mm with this technology under bipolar coagulation (Seal-safe modes).

Packing&Shiping

Packing information:

carton box package or customers requirements.

Size:600*450*300mm, Weight:8.0kg

HV-300B plus Electrosurgical Generator

Intelligent Device System
Microprocessor controlled with a wide TFT LCD Touch Screen, clean image quality. The settings and working modes of operation are changed by touching icons on the screen, ensures the users with easy access to all functions, satisfying all the surgeries demands with safety, flexibility, reliability and convenience.
Characteristics:
Equipment are designed for conventional Electrosurgical procedures with the ability to automatically adjust, designed for various operations.
Activation:
Designed to perform cutting and coagulation during surgical procedures, output activated by Handswitch or Footswitch

REM(Return Electrode Monitoring)
Return electrode (for Monopolar) with quality monitoring system(REM).
This REM system continually monitors patient impedance levels and deactivates the generator if a fault in the patient/return electrode contact is detected, at the same time with Audible and Visual Alarms, as well as real-time dynamic display of the contact quality on the screen between the negative plate and the patient's skin.

Automatic self-test
When switch on the machine, it will start automatically self-test routine prior to operation.
Real-time Monitoring and Instance Response System for Tissue Density
This proprietary technology delivers optimal clinical effects through continuous synchronization of current and voltage. It samples the current and voltage 450,000 times per second which enables it to respond to tissue impedance changes in less than 10 milliseconds, which ensuring the machine achieves optimum energy output levels quicker and more accurately – ensuring that only the precise voltage needed is safely delivered to each tissue type.

Monopolar Cut

-Multi Monopolar outlet, 3-pin (4mm) outlets and Laparoscopic Microphone head (4mm, 8mm ) outlet
-Different effects for cutting modes , pure cut for fast tissue dissection, while blend cut with a slight coagulation effect
Monopolar Coagulation
-Different coagulation modes provides precise, moderate, enhanced, contact-less coagulation effects
-Possibility of argon plasma coagulation

Bipolar
-Coagulation with Forceps for contact coagulation without sparking
Automatic Start /Stop
Under Bipolar cut and coagulation modes, user can choose Pedal control or Automatic control for the operation.

Ligasure Vessel Sealing (Seal-Safe)
With Bi-clamp or other instruments, enables permanent sealing up large blood vessels up to 7mm diameter under Seal-Safe working modes during open and lapaorscopic surgeries.
Endoscopic Vessel Sealing (Endo-Safe)
With Ligasure handles, enables permanent sealing up large blood vessels up to 7mm diameter under Endo-Safe working modes during Laparoscopic surgeries
Memory Records Features
Memory program that allows customize settings for different interventions and surgeons.

Upgrade Interface:

USB/RS232 interface available to connect with computer, which allows remote problem detect as well as further software upgrade.
Compatible with other Equipment

1. Argon gas module.
2. Optimum Smoke Evacuation System

Multilanguage Available
Language options: English, Spanish, Portuguese, Turkish and etc.

Application of Use
General Surgery; Gastroenterology, Dermatology;
Vascular Surgery; Obstetrics and Gynecology
Heart/Thoracic Surgery; ORL/ENT; Minimally Invasive Surgery(MSI)
Cerebral surgery; Neurosurgery, Orthopedics & Plastic Surgery;
Trans Urethral Resection (TUR) and etc.

Certificate

Machines are qualified by internationally recognized construction standards such as: CE, FDA, ISO 13485, ISO 9001.
